RG 6/U-4 Cu/Al

RG 6/U-4 Cu/Al

RG 6/U-4 Cu/Al


RG 6/U-4 Cu/Al
  • It is used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation is required.

Conductor
1,02mm Ø Electrolytic Copper
Insulation
4,60mm Ø Physical Foam PE
1.Screen Al-Pes Tape (100% Coverage)
2.Screen
Aluminium Braid
Sheath
6,80mm Ø PVC Compound White
Total Weight 47kg/km
Standard Length 100/500/1000/2000m

INSULATION
RESISTANCE
MUTUAL
CAPACITANCE
VELOCITY OF
PROPAGATION
OPERATING
VOLTAGE
TEST
VOLTAGE
BENDING
RADIUS
TEMPERATURE
RANGE
IMPEDANCE FLAME RETARDANT
TEST
>2000MΩxkm 53±2 pF/mt 2 % 1,3 kV 3 kV 20x Cable Ø -40ºC+70ºC 75±3 Ω IEC 60332-1-2
DIN EN 60332-1-2
EN 60332-1-2
